- 45 -
en
(transmitters) and the PARI compressor, as recommended
below in accordance with the maximum output power of the
communication device.
Safety distance depending on transmitting frequency:
Rated power
of the
transmitter [W]
150 kHz to 80
MHz
D = (3.5/3) ×
SQRT(P) [m]
80 MHz to 800
MHz
D = (3.5/3) ×
SQRT(P) [m]
800 MHz to
2.5 GHz
D = (7/3) ×
SQRT(P) [m]
0.01
0.2
0.2
0.3
0.1
0.4
0.4
0.8
1
1.2
1.2
2.3
10
3.8
3.8
7.3
100
12
12
23
For transmitters whose rated power does not appear in the table
above, the safety distance can be calculated using the equation
associated with the respective column, where "P" is the rated
power of the transmitter in Watt (W) according to the information
supplied by the device manufacturer.
Ambient temperature
+10 °C to +30 °C
Relative humidity
30% to 75% (non-condensing)
Atmospheric pressure
700 hPa to 1,060 Pa
6.5 Ambient conditions for operation
