Ref. No. Part No. Description Qty.
1 201-2 Upright 2
2 232-2 Split Nylon Bushing 4
3 204LS Left Pivot Bushing 1
4 211S Main Shaft 1
5 209-2 Shaft Adjusting Collar 2
6 229 Spring 1
7 204RS Right Pivot Bushing 1
8 212S Locknut, 1/2 - 13 1
9 213S Upright Adjustment Knob 1
10 225-2 Bolt, 3/8 - 24 x 2-1/4” 2
11 231-2 Washer, 3/8” SAE 2
12 230-2 Thin Nylon Locknut, 3/8 - 24 2
13 233-2 Thin Nylon Locknut, 1/2 - 20 2
14 234-2 Washer, 1/2” x 7/8” 2
15 235-2 Split Nylon Bushing (left side) 1
235-2R Split Nylon Bushing (right side) 1
16 214-2 Base 1
17 217S Caliper Arm Adjusting Knob and Shaft 1
18 206-2 Spring 1
19 207-2 Caliper Arm 1
20 White Background Decal 1
21 224S Caliper Adjusting Knob and Shaft 1
22 228-2R Caliper Spacer Spring 2
23 222SR Right Spring 1
24 222SL Left Spring 1
25 226-2 Thin Nylon Locknut, 1/4 - 20 2
26 219-2L Left Caliper 1
27 219-2R Right Caliper 1
28 748-1 Needle Bearing 2
29 749-1 Bearing Washer, 1/2” TRA815 4
REPLACEMENT PARTS LIST FOR PROFESSIONAL WHEEL TRUING STAND TS-2
30 209 Socket Head Cap Screw, 8-32 Thread 2
