7.3 Techincal data
11
ICEP007-030
Address Display label App type Default Min Max Unit Read Only Note
16434 dPS USINT 5 0 60 Sec FALSE Delay switching off pump (sec)
16435 dPA USINT 5 0 60 Sec FALSE Delay switching ON pump (sec)
16478 PP2 INT 0 0 3 FALSE Enable dubble pump 0=single pump; 1=automatic double pump; 2=manual pump1; 3=ma-
nual pump2
16484 t2P INT 30 1 72 Hours FALSE Time switch pump with PP2=1
16440 AbrA USINT 2 0 2 FALSE Start working mode of antifreeze resistor
16437 FUA BOOL FALSE(0) FALSE(0) TRUE(1) FALSE Antifreeze resistor
16388 Ud4E BOOL FALSE(0) FALSE(0) TRUE(1) FALSE Enable antifreeze resistor 0=disabled
16442 dLP USINT 2 0 10 Minutes FALSE Delay low pressure alarm
16443 dLE USINT 12 0 dPon Sec FALSE Delay water tank empy (sec)
16475 LEDP BOOL TRUE(1) FALSE(0) TRUE(1) FALSE H2O alarm selection 0=level 1=differential
16444 ddP USINT 8 0 60 Sec FALSE Delay alarm water pressure switch
16418 dE1 UINT 0 0 600 Sec FALSE Low temperature alarm delay (seconds)
16459 Arq BOOL TRUE(1) FALSE(0) TRUE(1) FALSE Enable control panel heater TRUE=SRQL FALSE=SRQH
16462 FdP USINT 1 0 2 FALSE Fan disable parameter 0=No effect on fan, 1=FAN3 OFF, 2=FAN 2 and FAN3 OFF;
16453 S1F1 INT 160 0 300 bar FALSE Set 1 fan 1
16454 S2F1 INT 140 0 300 bar FALSE Set 2 fan 1
16455 S1F2 INT 170 0 300 bar FALSE Set 1 fan 2
16456 S2F2 INT 150 0 300 bar FALSE Set 2 fan 2
16457 S1F3 INT 185 0 300 bar FALSE Set 1 fan 3
16458 S2F3 INT 165 0 300 bar FALSE Set 2 fan 3
16463 FSMi INT 140 0 250 bar FALSE Fan speed control minimun set At min set fan is OFF
16464 FSMA INT 185 50 300 bar FALSE Fan speed control maximun set
16480 ABO BOOL FALSE(0) FALSE(0) TRUE(1) FALSE Abilitazione Olio
16481 DOI USINT 120 10 600 sec FALSE Ritardo allarme olio (DIL6)
9205 C1H UINT Hours TRUE Compressor 1 working hours
9206 C1HL UINT kHours TRUE Compressor 1 working hours (x1000)
9207 C2H UINT Hours TRUE Compressor 2 working hours
9208 C2HL UINT KHours TRUE Compressor 2 working hours (x1000)
9209 UPH UINT Hours TRUE Unit partial working hours
9210 UPHL UINT kHours TRUE Unit partial working hours (x1000)
9230 H2OR BOOL 0 TRUE H2O water request
9231 HPS1 BOOL 0 TRUE High pressure switch 1
9232 HPS2 BOOL 0 TRUE High pressure switch 2
9233 PMPT BOOL 0 TRUE Pump termal protection
9234 HTC1 BOOL 0 TRUE High temperature switch compressor 1
9235 HTC2 BOOL 0 TRUE High temperature switch compressor 2
9236 PHAS BOOL 0 TRUE Phase monitor
9237 LH2O BOOL 0 TRUE Low H2O level
9238 ONOF BOOL 0 TRUE Remote On Off
9239 LPS1 BOOL 0 TRUE Low pressure compressor 1
9240 LPS2 BOOL 0 TRUE Low pressure compressor 2
9241 ALRM BOOL 0 TRUE Output alarm relay
9242 UAL1 BOOL 0 TRUE Output valve 1
9243 UAL2 BOOL 0 TRUE Output valve 2
9244 CMP1 BOOL 0 TRUE Compressor 1 output
9245 CMP2 BOOL 0 TRUE Compressor 2 output
9246 FAN1 BOOL 0 TRUE Output FAN 1
9247 FAN2 BOOL 0 TRUE Output FAN 2
9248 FAN3 BOOL 0 TRUE Output FAN 3
9249 H2OU BOOL 0 TRUE Output for H2O valve
9250 PUMP BOOL 0 TRUE Output pump
