⦁ Install the battery (not included) in the battery box. Attach the red cable to
the positive terminal of the battery, and the black cable to the negative
terminal of the battery as shown below in figure 1.2.]
Note: The small White and Black wires in the picture are for the battery
charger.
The White wire is Positive (+) and the Black wire is Negative (-).
Note: The Parkit360 requires a 12-Volt, Group (size) 24 deep-cycle RV or
Marine battery. The battery is not included with the unit, and must be
purchased separately.
6
