OperationStart-up / Operation
Using the router tool
Press and hold the spindle lock key
10
.
Release the union nut
3
with the open-ended
spanner
27
by turning it anticlockwise.
Release the spindle-lock key
10
.
Then use the router tool. This must be inserted
at least 20 mm (shaft length).
Tighten the union nut
3
firmly with the open-
ended spanner
27
.
Attaching the extractor adapter
Put the extractor adapter
21
on the drilling ex-
tractor
18
provided.
Screw together the extractor’s screws
22
and
the under side of the base plate
7
.
Connect a vacuum device approved for the
extraction of sawdust and splinters to the ex-
tractor
21
(see Fig. G).
Reducer
Connecting:
Slide the reducer
28
in to the suction adapter
21
.
Slide the hose for an approved dust extraction
unit (e.g. a workshop vacuum) onto the reduc-
er
28
.
Removal:
Pull the hose of the vacuum unit off of the re-
ducer
28
.
Pull off the reducer
28
.
Changing the collet
Note: All router bits of the router sets have a 8 mm
shaft.
Start with the already installed collet 8 mm
4
.
Change the collet for a router bit with a 6 mm shaft
as described below.
Release the union nut by turning it anticlockwise
using the open-ended spanner
27
until the collet
8 mm
4
is removed.
Insert the collet 6 mm
23
.
ATTENTION! Tighten the union nut
3
firmly
with the open-ended spanner
27
once the rout-
er bit
17
is inserted. Otherwise the collet might
be damaged.
Fitting the guide fence
Unscrew the both of the sliding bar’s
29
screws with a Philips screw driver.
Secure the sliding bar
29
to the rip fence
24
and
tighten the screws.
Operation
Switching on and off
Switching on:
Press and hold the start lockout
20
.
Activate the ON / OFF switch
19
. Once the
machine has started, release the start lockout
20
.
Switching off:
Release the ON / OFF switch
19
.
Presetting the speed
Set the desired speed using the speed setting
wheel
1
.
1–2 = low speed
3–4 = middle speed
5–7 = high speed
Set the milling depth
1. Ensure that the clamping lever
16
is locked down .
If it is loose turn it anti-clockwise until it is locked.
2. P
lace the device on the work piece to be wo rked
upon.
3. Turn the step stop
9
until it locks into the lowest
position.
4. Loosen the lock screw
11
.
