Parkside 291647 - Package Contents; Technical Data

PHDB 4 B2
GB
│
MT
│
21 ■
Float chamber
Oil plug
Transport oil plug
Intake filter
Hose connection adapter (pre-assembled)
Water suction hose
Oil inlet/dipstick
Automatic oil switch-off
On/Off switch
Water outlet
Water inlet
High-pressure pump
Temperature relief valve
Spark plug spanner
2x axles
Funnel
2x R-clips
2x screws (M6 x 55) (upper spray gun holder)
2x screws (M8 x 50)
2x screws (M6 x 12) (lower spray gun holder)
2x washers (Ø24 x Ø6.3)
1x screws (M6 x 45)
1x screws (M6 x 45)
2x nuts (M8)

2x washers (Ø19 x Ø8.3)

4x washers (Ø20 x Ø12)

4x nuts (M6)

Open end wrench (SW 10/12)

Nozzle cleaner needle (can be found in the operating instructions)

Allen key (M5/M6)
A Curved handle
Package contents
1 engine unit
2 x wheels, Ø300mm x 80mm
1 x high-pressure hose 8 m, max. pressure 25 MPa (250 Bar),
max. 60°C, flexible
1 x self-primer hose, Ø 18mm (external) /
Ø 13mm (1/2" internal) x 3m, with filter
1 x hand spray gun, max. pressure 28 MPa (280 Bar), max. 60°C
1 x lance pipe
4 x high-pressure nozzle, (red, yellow, green, white)
1 x low-pressure nozzle / cleaning nozzle (black)
2 x rubber feet
1 x spark plug spanner
1 x open end wrench (SW 10/12)
2 x Allen keys (M5/M6)
2 x spray gun holder
1 x funnel
1 x nozzle cleaner needle (can be found in the operating instructions)
1 x assembly material
1 operating manual
Technical data
Engine
Type 1 cylinder
4-stroke air-cooled, pull starter
Displacement cm
3
208
Nominal output
at 3600 rpm
kW (HP) 4.1 / 5.57
Normal operating
speed
rpm 3600
Fuel tank l 3.6
Fuel
*suitable for
E10 fuel
Petrol, unleaded
Fuel consumption
at full load
l/h 2.0
Oil volume - engine l 0.6
Oil type – engine 15 W 40
Cut-out function at low oil level
Spark plug LD F7RTC
Water connection
Supply temperat-
ure max.
°C 40
Supply pressure
max.
MPa (bar) 0.6 (6)
Pump (self-priming)
Working pressure MPa (bar) 18 (180)
Max. working
pressure
MPa (bar) 22 (220)
Flow rate l/min 8.3
Max. flow rate l/min 10
Opening tem-
perature thermal
valve
°C >45
Inlet connection G3/4"
Outlet connection M22 x 1.5
Suction height m 1
Self-pumping
start time
min 1
Dimensions and weight
Length x width x
height
mm 645 mm ×
570 mm ×
970 mm
Typical operating
weight
kg approx. 30
