Parkside PBSA 12 A1 Original Instruction

5
G B I E
General description
The illustrations are on the
front and back fold-out
page.
Extent of the delivery
Carefully unpack the appliance and check
that it is complete:
- Cordless Drill
- Battery-charger
- Battery
- Storage case
- Instruction Manual
Pictured bit and drill not included.
Overview
1 Keyless drill chuck
2 Chuck ring
3 Torque adjustment ring
4 Battery Indicator
5 Speed selector
6 Direction of rotation switch
7 Battery
8 Battery release button
9 On/off switch
10 LED working light
11 Drill chuck aperture
12 Storage case
13 Charger
14 Charger power supply cord
15 Green LED
16 Red LED
17 Bitholder
Functional description
The cordless drill with two-speed gearing
has a 19+1 level torque adjustment, left/
right running, a removable keyless chuck,
a 6-point bitholder and an LED working
light.
Technical data
Appliance
Motor voltage ............................. 12 V
Idling speed
1st gear .............................0-350 min
-1
2nd gear .........................0-1200 min
-1
Maximum torque ..........................25 Nm
Span-chuck ............................ 0.8-10 mm
Weight (without battery charger) .....1.1 kg
Drilling capacity
for wood .......................... max. 25 mm
for steel ............................. max. 8 mm
Sound power level
(L
pA
) ......................66.5 dB(A); K= 3 dB
Sound power level
(L
WA
) ........................ 77.5 dB(A); K= 3 dB
Vibration (a
h
)
Drilling in metal ...................< 2.5 m/s
2
Screwdriving without impact .. < 2.5 m/s
2
K= 1.5 m/s
2
Battery (Li-Ion) ............ DCBK-70-12
Nominal voltage ......................... 12 V
Capacity ..................................... 1.5 Ah
Charging time ...................... approx. 1 h
Recharger ............ JLH201261500G
Nominal consumption .....................30 W
Uptake voltage/Input
........................... 100-240 V~, 50-60 Hz
Voltage output/Output
.................................12.6 V
1500 mA
Protection class ................................
II
Protection category ......................... IPX0
