1. Scope of delivery / parts list
2. General
Gas hot glue gun
Glue port
Gas regulator marking
Gas supply regulator
Handle
Gas refilling valve
Trigger
Stand
Piezo ignition
Nozzle
Inspection glass for heating chamber
Ventilation opening
2 Glue sticks
Butane refill cartridge Art. 1500002692
3
1
4
2
5
6
7
8
9
12
13
14
11
10
Description of the parts
This manual belongs to this product. It contains important information on safety, usage and
maintenance. Read the manual carefully before using the product. Pay particular attention
to the safety instructions and warnings. Failure to follow the instructions given in the manual
may result in serious injuries or damage to the product. Always include the manual when you
give the product to others. Keep this manual in a safe place for future reference.
