parktool DT-5.2 - Page 5

Assembly for Facing Disc Brake Flat Mounts
9mm Axle Open Dropout-Flat Mount
10mm Axle Open Dropout-Flat Mount
15mm Axle Thru Axle-Flat Mount
20mm Thru Axle Any Width - Flat Mount
12mm Axle Thru Axle Front - Flat Mount
12mm Axle Thru Axle Rear - Flat Mount
Use axle
from fork
or
or
9mm Axle
Open Dropout
100-150mm Width
10mm Axle
Open Dropout
135-210mm Width
20mm Thru Axle
Any Width
12mm Thru Axle Rear
135-215mm Width
12mm Thru Axle Front
100-165mm Width
15mm Thru Axle
100-165mm Width
