012-02815D Kilovolt Power Supply
Parts List
REFERENCE PART RATING
C1,C2,C3,C4,C5,C6,C7,
C8,C9,C11,C12,C13,C14,
C15,C16,C17,C18,C19 1N4007 1000V
C10 1500uF 50V
C20,C28,C30,C36 100uF 40V
C21,C33 0.47uF
C22,C34 10nF 63V
C23,C24,C25,C26,C27,
C29,C31,C32 0.1uF 63V
C35 220nF 63V
C201,C202,C203,
C204,C205,C206 0.22uF 1000V
D1,D2,D3,D4,D5,D6,
D7,D8,D9,D10,D11,
D12,D13,D14,D15,D16
D17,D18 GP02 1000V
D19 2W04M
D20,D21,D201,D202 1N4148
F1 T630/250
J1 777
M1 100ua KF86b
P1A,P1B 10K POT
Q1,Q4 BC557B
Q2,Q6 BD788
Q3,Q5 BD243C
R4,R41 100R
R7,R40 3K3
R8 12K4 1%
R10,R31 22K
R13,R15 47K
R1,R36 2K43 1%
R5,R42 22R 2W
R6,R43 82R
R9,R34 6K8
R11,R29 82K
R12,R14,R47,R48,R49 10K
R16,R19,R24,R28 10M
R17,R26 8K2
R18,R32 1K
R20,R33 75K 1%
R21,R30 4K7
R23 2K2
R27 1M
R2 274R 1%
R22,R39 270R
R3,R37 470R
R25,R50 820R 5W
R35 560R 1%
R38 68K
R44,R45 2K2 SIL
R46 47K NTC
R201,R202,R203,R204,
R205,R206,R207,R208 390K
R209,R211 15M
R210,R212 12M
SW1 C5403FQ
TF1,TF2 14445
TF3 16566
TF4 16567
TR1,TR2,TR201 10K TRIM
TR3,TR5 4K7 TRIM
TR4,TR6 2K2 TRIM
TR7,TR8 47K TRIM
U1,U6 NE555
U2,U4 LM324
U3,U7,U8 LM317
U5 LM317L
