X2.5 Owner’s Manual
Gain, Balanced selectable 4 dB
or 14 dB output
Gain, single-ended selectable 4 dB
or 14 dB output
Freq. Response -3 dB @ 2 Hz
-3 dB at @ 100 kHz
Distortion @ 1KHZ < .1 % THD, typically
.003% @ 2 volts
Maximum Output 10 volts rms. bal out
7 volts rms. unbal
Output Impedance 200 ohms unbal
750 ohms balanced
Input Impedance 33 kOhm unbal
66 kOhm balanced
CMRR typ. -55 dB, 1KHz
Crosstalk typ. -85 dB, 1KHz
Output Noise floor < -125 dBV, 20Hz
to 20 KHz
External amp turn on 12 volts DC 50 mA
continuous
Power Consumption 35 watts
Dimensions 17” W x 11.5 “D
x 3.5”H
Shipping Weight 28 Lbs in packing
X2.5 Specifications
