Passtech ZP100WR - ANNEX a Beep & LED Table

Version 1.2 - 11 - 2010-10-06
ANNEX A Beep & LED Table
Beep
LED
Description
1 x short beep
1 x Green(2sec)
OK
3 x short beep
3 x Red(2sec) flashes
Operation Error
3 x short beep
1 x Red & Green in turn(2sec)
Time over
Do-Re-Mi Melody
1 x Red & Green in turn(2sec)
Successful Set up / mode
change / Time setting
5 x short beep
5 x Red & Green
Low battery
Do-Re-Mi Melody
2 x Red & Green
Successful connection
between front and back
bodies.
1 x short beep
1 x Green
Off the Alarm by Master card
Melody
1 x Green (1.5 sec)
Successful registration of
Owner Card/ Master Card
Melody
1xGreen
Read Clear Card and delete
the information of O/M/U in
the memory of the lock.
Green and Red on/off
1) Owner Card is not
registered.
2) In case of Shift or Week-
day operation mode, Alarm
for shift or Time due.
Red on/off
Owner card is registered, but
Master card is not registered.
Green on/off
Owner & Master card are
registered, but User card is
not registered in Fixed Mode.
short beep : 0.3sec long beep : 1.5sec
