INSTRUCTION MANUAL
APPLICATION WITH PACKING STRAP
Pataco TURTLE
SI8S TURTLE
Place the magnetic detacher onto
clutch and press to open Turtle.
HOW TO REALEASE - APPLICATION WITH PACKING STRAP
SI8M TURTLE
Take out Turtle from packing
strap.
EN
APPLICATION WITH GLUE STRIPE
The surface of merchandise and Turtle
has to be cleaned with an alcohol pad
to ensure maximum glue force.
Remove the transportation
security clip
Insert base plate under the
cross of packing strap, make
sure packing strap is in the
slot of base plate.
Close Turtle on base plate and
press down until lock.LED
ashes once and speaker beeps
once indicate merchandize
protected.
Pull
Use the carton box as transport
device from cashier to stock!
