INSTRUCTION MANUAL
APPLICATION WITH SENSOR
Pataco TURTLE
SI8S TURTLE
Take o the release paper from the
sensor head.
SI8M TURTLE
Stick the sensor head onto
merchandise. Use a cable tie
for better holding if required
(optional)
EN
HOW TO REALEASE THE SENSING HEAD
Same as step 1 to 6 of
"Application with glue stripe".
Plug in the end of the sensor
cable into the socket.
Wiring the sensor cable around
the strain-relief.
Close the TURTLE and press
down until it locks.
HOW TO REALEASE - APPLICATION WITH SENSOR
Same as step 1 to step 3 of "How to realease - Application with Glue Stripe".
Take o the glued
sensor by rotating the
sensor head.
