23
6.5 Application range
When using the generator, make sure the total load is within rated output.
Otherwise, damage to generator may occur.
AC
Power
Factor
1 0.8-0.95 0.4-0.75
(Efficiency
0.85)
Rated
output
power
3,000W 2,400W 1,020W
Rated
voltage 12V
TIP:
• Application wattage indicates when each device is used by itself.
• The simultaneous usage of AC and DC power is possible but total
wattage should not exceed the rated output.
EX:
The overload indicator (1) comes on when total wattage exceeds the
application range. (See page 11 for more details)
Generator rated output
3,000W
Frequency Power factor
AC 1.0
3,000W
DC ---
100W (12V/8.3A)
OPERATION
