viii. Press EXIT until you reach the keypad output screen. Return the fan to REMOTE
mode. The fan should immediately start to speed up to match the master.
d. Repeat Steps (b) and (c) for each additional downstream follower. It is advisable to re-lock
each fan’s parameter set after adjusting the speed scale, reversing the instructions in Step
(b). This will prevent unnecessary tampering with fan drive parameters.
e. Once all followers have been properly scaled, return to the master fan and set the desired
speed for the daisy-chained system.
For additional questions concerning the daisy chain configuration,
contact Patterson engineering at (800) 768-3985.
THIS COMPLETES THE HIGH-5
DAISY CHAINING INSTRUCTIONS.
