Patterson RC - Recommended Spare Parts

9
RECOMMENDED SPARE PARTS FOR VIL PUMPS , Types RC, CC, and CS
Reference: Assembly Section for the Pump Type
INTERMITTENT DUTY
Number Description
7 Casing Ring
14 Shaft Sleeve (Type CC only)
65 Mechanical Seal
Gasket (casing)
CONTINUOUS DUTY
Number Description
2 Impeller
6 Shaft (Types RC and CS only)
7 Casing Ring
14 Shaft Sleeve (Type CC only)
26 Impeller Screw
40 Deflector (Types CC and CS only)
65 Mechanical Seal
314
Coupling and bolts
All Hardware (not shown)
Gasket (casing)
