6 RubiQ BUILD PLAN
© 2021 PCS Edventures, Inc.
1
ASSEMBLY
PARTS
CAUTION
Handle the RX antennas with care. DO NOT pull on the antennas. Too much tension will cause the wire
to separate and permanently damage the RX.
RX (Receiver) Antenna Tubes & Caps
1 2
Power Distribution Board (PDB)
3
2 2
