PDC spas Biscayne User Manual





GENERAL rev. 2020/04
Seating Capacity 7
Shell Material Acrylic
Dimensions (Domestic) 94” (7’10”) sq. x 39” (3’3”)
Dimensions (Export) 240 cm. sq. x 99 cm.
Water Capacity 650 Gallons ( 2,460 liters)
Dry Weight 908 lbs (412 kg.)
Skirt Material Permawood™
ELECTRICAL SYSTEM
Pump Information Reference Number Domestic (60Hz) Export (50Hz)
Pump #1 peak (continuous) HP 1 6.0 (3.0) HP 6.0 (3.0) HP
Pump #2 peak (continuous) HP 2 6.0 (3.0) HP 6.0 (3.0) HP
Air Bubbler 4 1.5 HP 1.5 HP
Electronics
Electrical Can 6 Balboa 501X1 in.kYE 5 Series
Voltage 240 230
Amperage 50 2x16 / 1x32 / 3x16
Heater H 5.5 KW 3.6 KW
Operation System
Main Spa Side Control 7 SmartTouch™ in.k1000 Series
SPECIAL FEATURES
Spa Pillows
4
Stainless Steel Jetting
Standard
Cascading Spouts/Control Valve WS, C
Standard
Allure2™ LED Lighting
Optional
Halo LED lighting™
Standard
SoundStream™ Audio
Optional*
V
L
WS
G
C
I
LE
7
A
E
I
E
V
OZ 6, H
5 1
2
LE
LE
I
I
I
E
E
E
A
A
G
G
G
G
O
O
G
LE
LE
LE
I
U
E
K
G
U
U
U
4
WATER SYSTEM** (photo ref.)
Ozonator Water Treatment System OZ
25 sq. ft. Filter, PowerFlo™ System
4 Slide Valves
5 MegaSwirl™ Jet A
31 Euro Jet w/eyeball E
15 Mega’assage™ Jet G
2 Ozone Jet O
19 Large Euro Jet LE
2 Diverter Valves V
4 Safety Suction U
1 Mini Skimmer K
6 Air Control I
1 Spa Light L
1 Drain Valve 5
7”
10”
wire
feed
