GENERAL rev. 2020/04
Seating Capacity 5
Shell Material Acrylic
Dimensions (Domestic) 90” (7’6”) x 79” (6’7”) x 37” (3’1”)
Dimensions (Export) 229 cm. x 201 cm. x 94 cm.
Water Capacity 325 Gallons (1,230 liters)
Dry Weight 800 lbs. (363 kg.)
Skirt Material Permawood™
ELECTRICAL SYSTEM
Pump Information Reference Number Domestic (60Hz) Export (50Hz)
Pump #1 peak (continuous) HP 1 6.0 (3.0) HP 6.0 (3.0) HP
Pump #2 peak (continuous) HP 2 6.0 (3.0) HP 6.0 (3.0) HP
Air Bubbler 4 1.5 HP 1.5 HP
Electronics
Electrical Can 6 Balboa 501X1 in.kYE 5 Series
Voltage 240 230
Amperage 50 2x16 / 1x32 / 3x16
Heater H 5.5 KW 3.6 KW
Operation System
Main Spa Side Control 7 SmartTouch™ in.k1000 Series
SPECIAL FEATURES
Spa Pillows 4
Stainless Steel Jetting Standard
Cascading Spouts/Control Valve WS, C Standard
Allure2™ LED Lighting Optional
Halo LED lighting™ Standard
SoundStream™ Audio Optional*
A
G
G
U
V
I
I
E
E
E
E
E
E
LE
LE
LE
OZ 6, H
WATER SYSTEM** (photo ref.)
U
U
U
E
E
5
1
4
2
Ozonator Water Treatment System OZ
25 sq. ft. Filter, PowerFlo™ System
4 Slide Valves
4 MegaSwirl™ Jet A
36 Euro Jet w/eyeball E
11 Mega’assage™ Jet G
2 Ozone Jet O
15 Large Euro Jet LE
2 Diverter Valves V
4 Safety Suction U
1 Mini Skimmer K
5 Air Control I
1 Spa Light L
1 Drain Valve 5
12”
36”
wire
feed
