PeakTech 5615 User Manual

-24-
5. Technical Specifications
Display
2.4“ Color LCD 320x240
Resolution of
infrared image
160 x 120
(35200 Pixel)
Fiel of view
37,2° x 50°
IFOV
5.48 mrad
Response waveband
8 µm to 14 µm
Pixel Pitch
17µm
NETD
< 40 mK
Min. Focus length
> 150mm
Meas. range
-20°C … +550°C
-4°F … + 1022°F
Accuracy
+/-2°C 2,0%
Image frequency
25 Hz
Emissivity
0.01 - 1.0, adjustable
Color palette
White heat
Black heat
Iron Red
Rainbow
Memory
included Micro SD 8GByte
File format
JPEG
Interface
Micro- USB
IP Class
IP 54 protection
Operating temperature
-10°C – 50°C
Storage temperature
-20°C – 60°C
Relative humidity
< 90% RH
Battery
3,6V DC /3,35 Ah Li-Ion
Battery life
Approx. 8 h
Drop Test
2 m (6,56 feet)
Dimensions (WxHxD)
59 x 196 x 78 mm
Weight
350 g
