FEEDBACK SIGNAL INPUT
Input Voltage: 0 to 2.5 VDC
External Feedback Potentiometer: 1K ohm
POWER SUPPLY OUTPUTS
+15V OUT (J2-8): 100mA maximum (not including
option module)
+5V OUT (J2-7): 20mA maximum
NOTE: Do not connect these outputs to other power supplies.
AC MOTOR OUTPUTS
Off-state Leakage Current: <15mA
Maximum Load Current @ 150F: 5A
ENVIRONMENTAL
Operating Temperature Range: 32 F to 150 F
Storage Temperature Range: -40 F to 185 F
Relative Humidity Range: 0 to 90 % (noncondensing)
Series 92 Specs
MOTOR
Brushless Capacitor Run
CE Compliant AC Motors
GEAR TRAIN
Permanently Lubricated
Rockwell Hardened
MOUNTING CONFIGURATION
ISO Bolt circle (F07)
ISO Output Drive: 17mm
MANUAL OVERRIDE
Fully De-clutchable
ENCLOSURE
NEMA Type 4X, or optional Hazardous Locations
Stainless Steel Trim
2 (Two) ½” FNPT Conduit Entries
POSITION INDICATION
Beacon Position Indicator
TEMPERATURE
150 F maximum Ambient Temperature
