Peaktronics DHC-100 Manual

DHC-100
2 U.S. Patent 7,466,100 applies to this product PEAKTRONICS
OUTLINE
FRONT PANEL
+2.5V
1
2
3
4
5
6
WIPER
GND
MOTOR 2 OUTPUT
NEUTRAL
MOTOR 1 OUTPUT
to Motor
to Feedback Pot
+15V OUT
1
2
3
4
5
6
8
+5V OUT
VOLTAGE CMD (+)
4-20mA CMD (+)
SIGNAL GND ( )
EARTH GND
L1 LINE
L2 NEUTRAL
to AC Power
to Signal
ELECTRICAL
CONNECTIONS
J1
J2
7
J3
OPTION MODULE
CONNECTOR
1
2
OVERRIDE INPUT
to Auto/Manual Station
J7
GND
J2J1
87654321654321
J3
FUSE
3.50" 0.25"
0.25"
#6 clear hole
(2) places
1.36"
1.36"
*1.32"
J7
* Add 0.04" when option module installed.
AUTO
MANUAL / FB POT CAL
CLOSE
OPEN
AUX CLOSE OUTPUT
AUX OPEN OUTPUT
COMMAND TYPE
LOSS OF COMMAND
DIGITAL
4-20mA
1-5VDC
0-5VDC
0-10VDC
LAST
MODE
Digital High Resolution
(BOTH OFF)
PEAKTRONICS
POSITION OUT CAL
FAULT
2-10VDC
DHC-100 117VAC
DHC-100A
234VAC
DHC-100B
24VAC

Peaktronics DHC-100 Specifications

General

Brand	Peaktronics
Model	DHC-100
Category	Controller
Language	English
