Page #2 background image
DHC-100
01-22-04 PRELIMINARY INFORMATION
2
U.S. Patent 4,803,481 applies to this product; other patents pending
PEAKTRONICS
OUTLINE
DHC-100
DHC-100A
DHC-100B
117VAC
234VAC
24VAC
AUTO
MANUAL / FB POT CAL
CLOSE
OPEN
AUX CLOSE OUTPUT
AUX OPEN OUTPUT
COMMAND TYPE
LOSS OF COMMAND
DIGITAL
4-20mA
1-5VDC
0-5VDC
0-10VDC
LAST
MODE
Digital High Resolution
AUX POSITION OUTFAULT
(FLASHING)
CAL (STEADY ON)
(BOTH OFF)
PEAKTRONICS
FRONT PANEL
