32
Specifications
Rated voltage: 100-240 V~ / 50/60 Hz
Power consumption: < 48 W
Power consumption standby: < 1 W
6.1 Channel power output: 6 x 5 W & 1 x 10 W
Frequency response: L/R CH (60 Hz - 20 kHz at +1 / -2 dB)
Sensitivity: L/R: 550 mV
Overload source e.m.f.: > 2 V
Separation: > 55 dB
S/N: 60 dB
Remote Control: > 5m
Dimensions (W x H x D): 215 x 215 x 215 mm
Weight: 6.0 kg
Operating/ambient temperature: -10 °C to +40 ˚C
No sound Verify that the power adaptor and its jack are
connected properly.
Make sure the power button is in ON position.
Make sure the appliance is ON (White LED is
on).
Check if the iPhone/iPod is connected properly
to the docking station.
Make sure the volume is set at a audible listen-
ing level.
Check if music is playing from your iPhone/
iPod.
Check if a cable a the LINE IN overrides the
iPhone/iPod playback.
No charging Check if the iPhone/iPod is connected properly
to the docking station.
Troubleshooting
