DO NOT WIRE TWO SOLAR PANELS IN SERIES！
support@pecron.com
Use two solar panels in parallel to charge the E1000 LFP
※ It is recommended to choose PECRON solar panels for optimal user experience! The VOC of a single solar panel should be
less than 60V, and the VMP should be greater than 11V.
11~60V-600W Max
8A 20A
DC INPUT
※ PV(XT60) Port Only work within 12V~60V Open Circuit voltage, exceeding 60V will damage the machine.
11~60V-600W Max
8A 20A
DC INPUT
MC4 Solar Charging Cable*1
Y Branch MC4 Charging Cable(+)*1
Y Branch MC4 Charging Cable(-)*1
(NOTE：This parallel charging cable sold separately)
