Pecron E1000 LFP - Page 9

11~60V-600W Max
8A 20A
DC INPUT
E1000
AC
DC
AC OUTPUT-1800W Max
18W*2
12V 20A Max
100W*2
5A
20A
10A
DC OUTPUT
11~60V-600W Max
8A 20A
DC INPUT
11~60V-600W Max
8A 20A
DC INPUT
USING SOLAR PANELS TO CHARGE THE E1000 LFP
XT60 Charging Port: PV(operating voltage) range 11V~60V, 600W maximum; VOC(open circuit voltage) of solar
panel/array must be less than 60V, otherwise, it will damage the unit! Do not wire more than two 36V solar panels in
series, or more than four 18V solar panels in series. (18V/36V stands for Vmp of the solar panel)
support@pecron.com
XT60 Charging Port:
PV11V~60V-600W Maximum Input
USING SOLAR PANELS TO CHARGE THE E1000 LFP
Charging the E1000 LFP with one solar panel
MC4 Solar Charging Cable *1
※ It is recommended to choose PECRON solar panels for optimal user experience! The VOC of a single solar panel should be
less than 60V, and the VMP should be greater than 11V.
