Pecron E1500 LFP - EXPANDABLE BATTERY; USING SOLAR PANELS TO CHARGE THE E1500 LFP

Two PECRON EP3000-48V power packs can be
cascaded using PECRON's dedicated MJ32 socket.
Do not expand with any battery modules other
than the PECRON's, this could damage the unit!
After cascade completion, the display will
show the percentage of the sum of E1500 LFP
and EP3000-48V.
USING SOLAR PANELS TO CHARGE THE E1500 LFP
1. DC5521 Charging Port: PV/DC 12V~18V, 100W maximum; VOC(open circuit voltage) of solar panel must be less than
25V;
2. GX16MF-5 Charging Port: PV(operating voltage) range 32V~95V, 700W maximum; VOC(open circuit voltage) of solar
panel/array must be less than 95V, otherwise, it will damage the unit! Do not wire more than two 36V solar panels in
series, or more than four 18V solar panels in series.
(18V/36V stands for Vmp, the operating voltage, of the solar panel)
3. If you have any questions, feel free to contact us：support@pecron.com
support@pecron.com
EXPANDABLE BATTERY
E1500
100V~120V-15A(MAX)
AC INPUT AC OUTPUT-2200W
DC 输出
12V-30A(MAX)
12V-5A 12V-10A
12V-10A
USB
100W 18W 18W
18W 18W 18W
32V~95V
700W(MAX)
12V~18V
100W(MAX)
DC INPUT
3 5
4
2 1
E1500
100V~120V-15A(MAX)
AC INPUT AC OUTPUT-2200W
DC 输出
12V-30A(MAX)
12V-5A 12V-10A
12V-10A
USB
100W 18W 18W
18W 18W 18W
32V~95V
700W(MAX)
12V~18V
100W(MAX)
DC INPUT
DC5521 Charging Port:
PV12V~18V-100W Maximum Input
GX16MF-5 Charging Port:
PV32V~95V-700W Maximum Input
