The Pecron E300 LFP is a portable power station designed to provide reliable power for various applications. It features a robust LiFePO4 battery and a range of output and input options, making it suitable for both indoor and outdoor use.

Function Description

The E300 LFP serves as a versatile power source, offering both AC and DC outputs, as well as USB-A and USB-C ports for charging a wide array of electronic devices. It includes a wireless charger for compatible devices. The unit is equipped with an LCD display that provides real-time information about its operational status, including input/output wattage, battery level, temperature, and remaining charge/discharge time.

Key functions include:

AC Output: Provides 100V~120V AC power, with a maximum continuous output of 600W.
DC Output: Offers 12V-5A via 5525 DC outputs and 12V-10A via a cigar port.
USB Charging: Features USB-A ports (5V, 9V, 12V, Max 18W) and USB-C ports (5V, 9V, 12V, 20V, Max 100W) for fast charging.
Wireless Charging: Supports wireless charging up to 15W.
UPS Function: The E300 LFP supports an Uninterruptible Power Supply (UPS) function. When connected to AC mains power, the AC output is given priority. If the external AC mains power is cut off, the AC output will automatically switch to supply power from the battery pack within 8-20ms. This feature ensures continuous power for connected devices. The maximum power is 600W under UPS function.
ECO Mode: In ECO mode, the AC charging power is reduced by 50%. If there is no operation for 1 minute, the screen automatically turns off. The power station will automatically shut down after 3 hours without any load.
Smart Display: The LCD screen provides comprehensive information, including wireless connection status, Bluetooth connection status, battery level, UPS function status, ECO mode status, fan working status, AC/DC input wattage, battery voltage, temperature alarm, equipment alarm, AC/DC output wattage, remaining charging time, remaining hours of charge/discharge, and remaining use time.

Important Technical Specifications

Capacity: 288Wh (19.2V, 15Ah)
Battery Type: LiFePO4 Battery. Retains 80%+ original capacity at 3500 cycles.
Temperature Range:
- Charging: 0°C~45°C / 32°F~113°F
- Discharging: -20°C~45°C / -4°F~113°F
Dimension: L10"xW6.8"xH6.1" (L254xW172xH154 mm)
Net Weight: Around 10.6lb (Around 4.8Kg)
Charging Time: Charges to 80% in 60 minutes and 100% in 80 minutes.
Protections: Over-Voltage, Overheat, Overload, Short-Circuit, Self-Recovery.

Output Specs:

*AC Output 2: 100V~120V, Max 600W
*USB-A 2: (5V, 9V, 12V, Max 18W)*2
*USB-C 1: (5V, 9V, 12V, 20V, Max 100W)*1
*Cigar Port 1: DC 12V-10A
*DC 5525 Output 1: DC 12V-5A
*DC 5525 Output 1: DC 24V-5A
*Wireless Charger 1: Max 15W

Input Specs:

*USB-C 1: DC 5V, 9V, 12V, 20V, Max 100W
*5521 1: DC Charging (12V~28V), Max 100W
*AC Inlet 1: AC 100V~120V, Max 300W
- Note: AC charge + 5521 DC charge + USB-C charge can work together, but the charge power will be limited at max 300W.

Usage Features

How to Use the E300 LFP:

Powering On/Off: Long press the ON/OFF button for the LED light to turn on/off. Short press to switch the brightness of the LED light.
AC On/Off: Press and hold to turn on/off AC. Short press to view voltage and frequency after turning on.
DC On/Off: Long press the ON/OFF button to control DC/USB/Wireless output. Short press to view battery voltage. (The AC power when E300 LFP is not in use for a long time is turned off.)

Charging the E300 LFP:

By AC Power: Connect the AC charging cable to the AC inlet on the device and plug it into a wall outlet. During charging by generator, ensure the voltage and frequency are stable to avoid damage.
By USB-C: Connect a USB-C cable to the USB-C input port and a compatible USB-C power adapter.
By Vehicle: Connect the car charging cable to the 5521 DC input port and plug it into your vehicle's cigar lighter socket.
By Solar Panel: Connect a solar panel (recommended PECRON solar panels for optimal user experience) to the 5521 DC input port. The VOC of a single solar panel should be less than 28V, and the VMP should be greater than 12V. MC4 solar charging cable is required (buy separately).

APP Function: The Pecron APP allows users to review product specifications, control the device, and set personalized features remotely. To connect, long press AC and DC switch together for 3 seconds. The WiFi icon will flash, indicating the pairing model is working. The APP can be found on Apple Store for iPhone users and Google Play for Android users.

Packing List: The standard package includes:

PECRON E300 LFP *1
AC Charging Cable *1
Car Charging Cable *1

Maintenance Features

Storage:

Turn off the unit and store it in a dry, ventilated place at normal room temperature. Avoid placing the unit near water sources or in a wet/moist environment.
For long-term storage, it is recommended to discharge the battery to 30% every three months and recharge it to 60% to sustain battery life.

General Care:

Avoid immersing the device in water.
Do not use the battery in a strong static electricity or electromagnetic environment.
Do not disassemble or puncture the product with sharp objects.
Short circuits can be caused by: vermin or pests chewing through wires; water or other fluids coming into contact with electrical wiring.
It's prohibited to be used as car jump starter, only can be used to charge the car battery.
Do not use accessories or parts other than those provided by PECRON.
When using this product, strictly follow the ambient temperature for use in the user manual. If the temperature is too high, the battery can potentially result in self-combustion and will burst into flames, which can cause widespread damage. If the temperature is too low, the performance of the battery will be seriously degraded, and it may even fail to meet the normal use requirements.
Do not stack heavy objects on this product.
Do not block the air vents during use, or leave the device in a non-ventilated or dusty space.
Avoid impacts, fall off, and violent vibration. Please turn off the device immediately and stop using it in the event of major exterior impact. Please fasten the unit firmly during transportation to avoid vibration and impact.
In the event of immersing the device into the water accidently, please place the unit in a safe open area and keep away from the unit until it is completely dry. The dried unit should not be reused and should be disposed of properly according to the local regulation. If the device catches fire, use the fire extinguishing equipment in the following recommended order: water or mist, sand, fire blanket, dry chemical, carbon dioxide fire extinguisher.
Wipe the device with a dry cloth to clean the surface.
Place this device with care to prevent the product from being damaged due to fall off. If the product is damaged due to fall off, please turn off the unit immediately and place it in an open area, keep away from combustibles and crowds, and dispose of in accordance with local laws and regulations.
Store this device in a place out of reach of children and pets.

Disposal:

When conditions permit, completely discharge the battery of this product, and then put the product in the designated battery recycling box. This product contains batteries that are dangerous chemicals and are strictly prohibited from being disposed of in ordinary trash. For details, follow local laws and regulations on battery recycling and disposal.
If the battery cannot be completely discharged due to the failure of the product itself, dispose of the battery directly in the battery recycling box, and contact a professional battery recycling company for further disposal.
If the battery is unable to start after being over-discharged, dispose of it according to the principle of disposal.

Exclusions: PECRON's warranty does not apply to: Misused, abused, modified, damaged by accident, or used for anything other than normal consumer use as authorized in PECRON's current product literature.
