peerless-AV DST980-3 - Page 5

5
2014-05-29 #:203-9401-4 (2014-09-30)
Parts (Before beginning, make sure you have all parts shown below).
Piezas (antes de iniciar, asegúrese de tener todas las piezas siguientes).
Pièces (avant de commencer, assurez-vous d’avoir toutes les pièces illustrées ci-dessous).
Teile (Achten Sie vor Beginn der Arbeiten darauf, dass alle unten abgebildeten Teile vorhanden sind).
Onderdelen (hoort u zich ervan te overtuigen dat u alle onderdelen hebt, die hieronder te zien zijn).
Parti (prima di iniziare, accertarsi di disporre tutte le parti sotto indicate).
Díly (předtím, než začnete, připravte si všechny díly zobrazené níže).
Diely (predtým, ako začnete, pripravte si všetky diely zobrazené nižšie).
Peças (antes de iniciar, certifi que-se de que tem todas as peças apresentadas em baixo).
Parçalar (Başlamadan önce, aşağıda gösterilen bütün parçaların elinizde olduğundan emin olun).
ENG
ESP
FRN
DEU
NEL
ITL
ČEŠ
SLK
POR
TÜR
Parts List
DST980-3
Part # Qty
DST975-4
Part # Qty
DST942-6
Part #Description Qty
A adaptor arm 3 146-1061 4 146-1061 6 146-1061
B center support 1 146-1066 1 146-1065 1 146-1066
C gusset arm 3 146-1069 4 146-1069 6 146-1069
D top center plate 1 146-1071 1 146-1071 1 146-1071
E bottom center plate 1 146-1072 1 146-1072 1 146-1072
F bottom cover bracket 4 146-1156 4 146-1156 4 146-1156
G bottom cover plate 1 146-1074 1 146-1074 1 146-1074
H M8 x 65mm screw bolt 12 520-1750 16 520-1750 24 520-1750
I M10 x 15mm round socket screw 24 520-9262 32 520-9262 48 520-9262
J M8 locknut 12 530-9408 16 530-9408 24 530-9408
K M4 hex nut 8 530-1417 8 530-1417 8 530-1417
L 1/4-20 thin stop nut 3 530-1046 4 530-1046 6 530-1046
M 1/4-20 x 1.5" socket screw 3 520-1009 4 520-1009 6 520-1009
N retaining collar 1 1800-375 1 1800-375 1 1800-375
O retaining collar washer 1 540-9432 1 540-9432 1 540-9432
P cable bushing 3 590-1295 4 590-1295 6 590-1295
Q tilt bracket 3 200-1552 4 200-1552 6 200-1552
R PLP plate 3 201-1110 4 201-1110 6 201-1110
S adaptor bracket 6 202-1656 8 202-1656 12 202-1656
T 4mm allen wrench 3 560-0072 4 560-0072 6 560-0072
U cable assembly, 1/8 1 600-0033 1 600-0033 1 600-0033
V wire rope clip, 1/8 1 560-0104 1 560-0104 1 560-0104
AA M4 x 12mm screw 12 504-9013 16 504-9013 24 504-9013
BB M4 x 25mm screw 12 504-1015 16 504-1015 24 504-1015
CC M6 x 12mm screw 12 520-1128 16 520-1128 24 520-1128
DD M6 x 25mm screw 12 520-1208 16 520-1208 24 520-1208
EE M8 x 12mm screw 12 520-9571 16 520-9571 24 520-9571
FF M8 x 25mm screw 12 520-1031 16 520-1031 24 520-1031
GG M4 washer 12 540-9400 16 540-9400 24 540-9400
HH M6/M8 washer 24 540-9406 32 540-9406 48 540-9406
II spacer 24 600-1215 32 600-1215 48 600-1215
JJ 6mm allen wrench 3 560-9716 4 560-9716 6 560-9716
KK M5 x 10mm phillips screw 13 520-9250 17 520-9250 25 520-9250
LL 5mm allen wrench 1 560-9640 1 560-9640 1 560-9640
