Parts (Before beginning, make sure you have all parts shown below).
Piezas (antes de iniciar, asegúrese de tener todas las piezas siguientes).
Pièces (avant de commencer, assurez-vous d’avoir toutes les pièces illustrées ci-dessous).
Teile (Achten Sie vor Beginn der Arbeiten darauf, dass alle unten abgebildeten Teile vorhanden sind).
Onderdelen (hoort u zich ervan te overtuigen dat u alle onderdelen hebt, die hieronder te zien zijn).
Parti (prima di iniziare, accertarsi di disporre tutte le parti sotto indicate).
Díly (předtím, než začnete, připravte si všechny díly zobrazené níže).
Diely (predtým, ako začnete, pripravte si všetky diely zobrazené nižšie).
Peças (antes de iniciar, certique-se de que tem todas as peças apresentadas em baixo).
Parçalar (Başlamadan önce, aşağıda gösterilen bütün parçaların elinizde olduğundan emin olun).
ENG
ESP
FRN
DEU
NEL
ITL
ČEŠ
SLK
POR
TÜR
M5 x 10mm
Parts List
EPT630
Part #Description Qty
A tilt plate assembly 1 096-T1619
B adaptor plate 1 096-T1614
C 8mm concrete anchor 2 590-0320
D #14 x 2-1/2" wood screw 2 520-5045
E M6 x 12mm 2 520-0661
F 1/4 x .5 x .069 washer 2 540-4620
G M5 x 10mm 1 520-0983
H 5/16" (8mm) height spacer 4 540-1509
I M4 x 10mm screw 4 520-2849
J M4 x 20mm screw 4 504-5000
I
(
4
)
M4 x 10mm
J
(
4
)
M4 x 20mm
H
(
4
)
5/16" (8mm)
height spacer
A (1)
tilt plate
assembly
B (1)
adaptor plate
C
(
2
)
8mm concrete anchor
D
(
2
)
#14 x 2-1/2" wood screw
E
(
2
)
F
(
2
)
G
(
1
)
M6 x 12mm washer
