peerless-AV Modular Series - Page 7

7
2019-03-25 #:056-9108-1
Y (1)
5mm allen
wrench
X
(
4
)
10mm concrete anchor
Z
(
1
)
M8 x 55mm
AA
(
4
)
3" wood screw
BB
(
1
)
M10 set screw
D (2)
G (2) H (1) I (3)
.25" ID spacer
(not used)
#10-32 x 3/8
socket pin screw
#10-32 x 3/8 serrated
head socket pin screw
10-32 x 3/16
set screw
N (1)
4mm allen wrench
F
(
1
)
#10-32 x 3/8
thumb screw
E
(
2
)
#14 x 2-1/2" wood screw
(not used)
C (1)
M5 x 10mm type-f
(not used)
