6 of 8
ISSUED: 11-15-11 SHEET #: 021-9014-2 10-15-12
Install two plastic covers (E) to back of
stand (A) with four M5 x 8mm screws (G).
For security installation tighten M5 x 8mm
socket pin screw (J) using security allen
wrench (K) to lock display to tilt assemby.
E
A
G or J
