peerless-AV SmartMount SR555M - Page 7

7
2014-02-16 #:009-9097-8 (2020-12-16)
Parts List
Part #Description Qty
A base 1 009-T1674
B caster (non-locking) 2 10000818
C caster (locking) 2 10000819
D vertical column 1 009-T1831-1
E 3/8"-16 x 1.5" 4 520-1329
F split washer 4 540-9424
G bracket 1 009-T1698-1
H M8 x 16mm 4 520-9527
I nut bar 2 202-T1882
J retaining washer 4 540-9494
K shelf nut 2 530-0098
L shelf knob 2 560-1871
M shelf 1 009-T1772
N column cover 1 009-1672
O 5mm allen wrench 1 560-9640
P 7/32" allen wrench 1 560-9715
Q adaptor bracket 4 202-SG1695
R camera shelf 1 009-T1808
S camera shelf extension 1 010-T1169
T camera shelf mount 1 010-T1170
U rail support weldment 2 010-T1175
V horizontal display adaptor 2 201-SG1944
W 1/4-20 x 1/2" washer head 16 520-1357
X M5 x 10mm 4 520-1063
Y M5 x 25mm 6 520-1122
Z 6-32 x 1/2" 4 520-9517
Parts List
Part #Description Qty
AA M8 x 15mm 4 520-1068
BB 4mm allen wrench 1 560-9646
CC M4 x 12mm 8 520-1079
DD M4 x 25mm 8 520-1082
EE M6 x 12mm 8 520-1050
FF M6 x 25mm 8 520-1211
GG M8 x 12mm 8 520-1724
HH M8 x 25mm 8 520-1101
II M4 x 1mm washer 8 540-9400
JJ M6/M8 x 1.5mm washer 20 540-9406
KK 1/4" (6mm) height spacer 16 600-1215
LL 7/32" hex power bit 1 560-0905
MM M8 x 50mm 8 521-1013
NN base foot 4 009-1846
OO M5 x 13mm self-tapping 8 520-1616
PP 4mm security driver 1 560-1133
QQ shoulder washer 2 540-1668
RR camera support bracket 2 010-T1171
SS joint bracket 2 010-T1173
TT 1/4-20 x 2.5" hex bolt 6 520-1322
UU 1/4-20 nylock nut 6 530-1007
VV 1/4 x .062 at washer 12 540-9440
WW tube cap 4 591-1041
Parts (Before beginning, make sure you have all parts shown below).
Piezas (antes de iniciar, asegúrese de tener todas las piezas siguientes).
Pièces (avant de commencer, assurez-vous d’avoir toutes les pièces illustrées ci-dessous).
Teile (Achten Sie vor Beginn der Arbeiten darauf, dass alle unten abgebildeten Teile vorhanden sind).
Onderdelen (hoort u zich ervan te overtuigen dat u alle onderdelen hebt, die hieronder te zien zijn).
Parti (prima di iniziare, accertarsi di disporre tutte le parti sotto indicate).
Díly (předtím, než začnete, připravte si všechny díly zobrazené níže).
Diely (predtým, ako začnete, pripravte si všetky diely zobrazené nižšie).
Peças (antes de iniciar, certique-se de que tem todas as peças apresentadas em baixo).
Parçalar (Başlamadan önce, aşağıda gösterilen bütün parçaların elinizde olduğundan emin olun).
ENG
ESP
FRN
DEU
NEL
ITL
ČEŠ
SLK
POR
TÜR
