Parts (Before beginning, make sure you have all parts shown below).
Piezas (antes de iniciar, asegúrese de tener todas las piezas siguientes).
Pièces (avant de commencer, assurez-vous d’avoir toutes les pièces illustrées ci-dessous).
Teile (Achten Sie vor Beginn der Arbeiten darauf, dass alle unten abgebildeten Teile vorhanden sind).
Onderdelen (hoort u zich ervan te overtuigen dat u alle onderdelen hebt, die hieronder te zien zijn).
Parti (prima di iniziare, accertarsi di disporre tutte le parti sotto indicate).
Díly (předtím, než začnete, připravte si všechny díly zobrazené níže).
Diely (predtým, ako začnete, pripravte si všetky diely zobrazené nižšie).
Peças (antes de iniciar, certique-se de que tem todas as peças apresentadas em baixo).
Parçalar (Başlamadan önce, aşağıda gösterilen bütün parçaların elinizde olduğundan emin olun).
ENG
ESP
FRN
DEU
NEL
ITL
ČEŠ
SLK
POR
TÜR
Parts List
Part #Description Qty
A base 1 009-T1675
B caster (non locking) 2 600-1391-1
C caster (locking) 2 600-1392-1
D vertical column 2 009-T1831-1
E 3/8"-16 x 1.5" long bolts 8 520-1329
F split washer 8 540-9424
G bracket 2 009-T1693
H 5/16-18 socket screw 8 520-9549
I nut bar 4 010-T1123
J M6/M8 washer 12 540-9406
K retaining washer 8 540-9494
L adjustment bracket 2 009-1694
M knob 2 560-1159
N column cover 2 009-1672
O horizontal display adaptor 1 145-T1816-1
P vertical adaptor bracket 2 009-T1923-1
Q M6 x 12mm socket pin screw 4 520-1050
R M6 x 25mm socket pin screw 4 520-1211
S M8 x 12mm socket pin screw 4 520-1724
T M8 x 25mm socket pin screw 4 520-1101
U washer 8 540-9406
V .25" height spacer 8 600-1215
W 3/16" allen wrench 1 560-0071
X 7/32" allen wrench 1 560-9715
Y 4mm allen wrench 1 560-9646
Z 7/32" hex power bit 1 560-0905
AA base foot 4 009-1846
BB M5 x 13mm self-tapping 8 520-1616
CC 4mm security driver 1 560-1133
DD M8 x 16mm 8 520-9527
EE 5mm allen wrench 1 560-9640
FF M8 x 50mm 4 521-1013
