GANCIOMATIC SYSTEM
The Ganciomatic system is a fast, practical
way to fasten the Primo Viaggio car seat to
the stroller, using the Ganciomatic fasteners.
The Primo Viaggio car seat is also equipped
with a Ganciomatic System, and can be
purchased separately. The Primo Viaggio car
seat fastens to its own base (which is left in
the car) and to the stroller, so the child can be
moved without being disturbed. The Venezia
stroller allows you to fasten the car seat
two different ways (“A” and “B”).
GANCIOMATIC FASTENERS ON THE
STROLLER
41• To raise the Ganciomatic fasteners on the
stroller, lift the sack at the corners of the
seat and turn the two fasteners upward.
The fasteners will automatically move
outwards.
42• To lower the Ganciomatic fasteners on
the stroller, pull the lever upwards while
lowering the hook, as shown in the
figure.
• The Venezia stroller can be folded up
with the Ganciomatic fasteners raised or
lowered.
VENEZIA + PRIMO VIAGGIO
43• To fasten the car seat to the stroller in
the “A” VERSION:
- set the brake on the stroller;
- remove the hood from the stroller;
- lower the backrest on the stroller to the
lowest position;
- raise the Ganciomatic fasteners on the
stroller;
- turn the handlebar to the opposite side
from the backrest;
- place the car seat facing the handlebar;
- fasten the car seat by pressing down on it
until it clicks into place.
44• To fasten the car seat to the stroller in
the “B” VERSION:
- set the brake on the stroller;
- remove the hood from the stroller;
- lower the backrest on the stroller to the
lowest position;
- raise the Ganciomatic fasteners on the
stroller;
- make sure the handlebar is on the same
side as the backrest;
- pull the front bar out until it clicks into its
first position;
- place the care seat facing the backrest;
- fasten the car seat by pressing down on it
until it clicks into place.
• To detach the car seat from the stroller,
consult the instruction manual for the car
seat.
LINE OF ACCESSORIES
45• Cover All Rain Canopy: Rain canopy in
24• Fasten the hood to the inner sides of the
armrests, stretch out the hood, and press
down on the side braces as shown in the
figure.
25• To turn the hood into a canopy to shield
the child from the sun, open the zipper
as shown in the figure and undo the rest
of the hood.
COVER
• To transform Uno into the carriage
version, first extend the front bar to the
second position and lift the footrest
26• Slip off the lower part of the hood from
under the footrest sack.
27• Insert the tabs on the lower part of the
cover into the slots in the front bar. (The
slots on the front bar flip out when the
front bar is extended. If the slots slide
back into their housing, pull the two little
levers under the front bar towards you.)
28• Insert the side eyelets into the armrests.
29• Baby carriage without cover.
30• Zip the upper part of the cover to the
lower part and button to the armrests as
indicated in the figure.
31• Carriage version with cover.
CLOSING THE STROLLER
Before closing the stroller, check to make
sure that the handlebar is positioned on
the same side as backrest. If the hood is
attached, pull the side braces upwards.
Make sure the four wheels are fixed.
32• To close the stroller, lower the right-
hand lever (marked "1") until it clicks into
place.
33• Lower the left-hand lever (marked "2"),
and lift the handlebar upwards.
34• Lower the handlebar to finish closing the
stroller, and close the catches as shown
in the figure.
TRANSPORT
35• The stroller has a handle on each side,
which together allow you to transport it
when open (as when going down stairs)
or closed.
REMOVABLE LINING
36• To remove the lining from the stroller,
remove the flaps on the sack from the
armrests and unfasten the buttons.
37• Remove the sack flap from the backrest.
38• Pull the safety belt out from under the
seat.
39• Loosen the safety belt from both sides,
and slip the sack off the stroller.
40• To wash the part below the cover, undo
attachments from fittings found on
the footrest chassis as indicated in the
figure.
