HUM2ESXX CONFIGURATION
- To exit the menu once the configuration values are set, simultaneously keep keys (5) and (6)
pressed for a few seconds until the cell humidity value appears again (displays 0.0 if ON/OFF).
Memorisation of the amendments made to the variables will happen automatically when exiting the
configuration menu.
Press the ON/OFF - STAND-BY key to enable the electronic control (when you enter 2nd level
programming, the humidifier automatically switches to STAND-BY mode).
DEFAULT
VAR. MEANING VALUES
ES-3M
ES-6M
ES-12
ES-6 ES-24 ES-48
S0
Pump discharge duration time for deconcentration. 0.1 ÷ 12.7 s 2 2 3 5
S1
Hours of work Tenths of hours - - - -
S2
Discharges for deconcentration interval. 1 ÷ 250 min 15 15 15 15
S3
Delay time in insertion of electrodes after any pump discharge. 1 ÷ 12 s 2 2 2 2
S4
Water discharge after inactivity 0 – 24 h 1 1 1 1
S5
Minimum current differential between one water charge and
another.
0.2 ÷ 10 A 1 0,7 1 1
S6
Percentage of discharge pump activation 1 ÷ 50 % 25 25 20 15
S7
Pump discharge duration time for overcurrent. 0.1 ÷ 5.0 s 0.5 0.5 0.5 0.5
S8
Minimum current differential for water charge. 0.0 ÷5.0 A 0.1 0.1 0.3 0.5
S9
Functioning setting 0 ÷ 8 0 0 0 0
S10
Discharge Test 0 ÷ 1 1 1 1 1
CA1
Humidity probe calibration -20 % ÷ 20 % 0 % 0 % 0 % 0 %
CA2
Channel humidity probe calibration -20 % ÷ 20 % 0 % 0 % 0 % 0 %
CA3
NTC probe value correction -10.0÷ 10.0 °C 0,0 0,0 0,0 0,0
t1
Delay in seconds to humidifier re-start 0-240 s 10 s 10 s 10 s 10 s
t2
Functioning time ON for essence. 1-30 s 2 s 2 s 2 s 2 s
t3
Functioning time OFF for essence. 0-99 min 5 min 5min 5min 5 min
t4
Timer for manual insertion outlet fans. 0-24 hrs 0=Dis. 0 0 0 0
In2
Digital input In2 and activation status setting.
0 ÷ 9
1 1 1 1
In3
POWERED input In3 and activation status setting.
0 ÷ 9
0 0 0 0
dO4
Digital output dO4 functioning setting.
-3 ÷ 4
1 1 1 1
dO5
Digital output dO5 functioning setting.
-3 ÷ 4
0 0 0 0
HSE
Maximum value attributable to set point 0 ÷ 99 99 99 99 99
Ad
MODBUS-RTU network address or master-slave
configuration.
0 ÷ 247
1 1 1 1
MS
Master-Slave setting (with MS=0 modbus is enabled) 0 ÷ 6 0 0 0 0
rEL
release software MASTER read only 11 11 11 11
6
