INSTALLATION INSTRUCTIONS
Name of components
1.Base Installation：
Align the tube with the
groove on the base. Fix
them together by screwing
the nut at bottom..
Position the rear grill
against the motor so that
the pins on the motor fit
through the matching holes
of the rear grill.
Tube
Motor
Motor shaft
Rear grill
Tighten
knob
3.Install by
aligning
Base
Nut
Considerate Hint:
Remove parts from the component
before performing installation.
RULES FOR SAFE OPERATION
1. Never insert fingers, pencils, or any other object through the
grill when fan is running.
2. Disconnect the fan when moving from one location to another.
3. Be sure the fan is on a stable surface when operating to avoid
overturning.
4. DO NOT use it by window, rain may create electrical hazard.
5. Household use only.
3.Install the Rear grill:
2.Connect the Tube to
Motor:
Adjusting the
tighten knob and insert
the motor part.
