INSTALLATION INSTRUCTIONS
Name of components
Pole
Motor
Rear grill
Tighten
knob
Install by
aligning
Base
Right-angle bolt
Considerate Hint:
Remove parts from the
component before performing
installation.
Base Installation
Align the column with the
groove on the base and
fix them together using a
right-angle bolt.
INSTALLATION INSTRUCTIONS
