Arctica 4804iq Series switch Installation Guide Chapter 1 Introduction
Indicator light
Panel sign State Meanings
Power supply
indicator light
P-1 / P-2
Green light
always on
Power supply module move
normally.
Amber light
always on
Power make a mistake
Put out No power supply
System
automatic
diagnoses LED
STAT
Green light
always on
System running normal.
Green light winks System booting
Work mode
indicator light
MAST
Green light
always on
Master mode
Amber light
always on
Slave mode
Table 1-3 The explanation of the port indicator light
Indicator light
Panel sign State
ETHERNET port
Link light (right)
Green The port is under the connection state of 10M,
100M o
1000M.
Green winks The port is transmitting data
Put out No connection or fail to connect.
Indicator light of
SFP+ port
Green The port is unde
the connection state of 1G/10G.
Green Wink The port is transmittin
data.
Put out No connection or fail to connect.
Indicator light of
RJ45 port
Green The port is unde
the connection state of 1G.
Amber The port is under the connection state of
10M/100M.
Green Wink The 1G port is transmitting data.
Amber Winks The 10M/100M port transmitting data.
Put out No connection or fail to connect.
