53
STEP #10
Cc-3
Gg-3
Gg-3
Cc-3
B-3
B-3
B-3
B-3
G-3
G-3
G-3
G-3
D-3
D-3
D-3
D-3
10. Attach the Sliding Door Frame (D-3), Frame Next To Door (B-3) and Bottom Door Rail
(G-3) together with Bolts (Cc-3) and Washers (Gg-3).
NOTE:
Be sure measurements diagonally across the overall frame are within 5mm of the same
distance after completing this step
±5mm
