16. Before leaving the installation, run the system through at least one complete operating cycle to be sure the
valve is operating correctly.Renewal Kits
Table 1: Renew Kits (Part 1 of 2)
Individual Part
Description
Commercial Type: V46A, V46D, V47A, V47N Maritime and
Navy Type: V46B, V46C
Diaphragm
Kits for
All Types
Seat Guide Post 111111 11111
Disc Stud 111111 11111
Disc Cup (Retainer) 1 1 1 1 1 1 1 1 1 1 1
Valve Disc 11111111111111
Valve Seat 11111111111111
Valve Stem 111111 11111
Rubber Diaphragm
1
44445555444555 5 5
Guide Plate Gasket 11111111111111 1 1
Bellows Sealing Ring 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
Valve Assembly Screw 1 1 1
Guide Post 1 1 1
Valve Disc Retainer 1 1 1
Figure 8: Guide Plate Gasket and
Bellows Sealing Ring Identification
Gasket
for pressure
Push Rod

Penn V46 Series Specifications
