3
Installation
Regardless of when or by whom your vessel may have been installed, there are a few quick checks you should
make before use. Check that each vessel is:
Mounted with compliant material (Polyurethane saddle) between the fiberglass shell and any rigid frame.
Free to expand under pressure - shell not clamped rigidly in place, no rigid piping connections to port fittings.
Not used in any way to support other components such as piping, manifolds hanging from ports.
Section through end closure
Filament Wound epoxy/ glass composite. Head
locking grooves internally wound in place. Shell
exterior coated with Blue high gloss polyurethane
paint.
Ethylene Polypropylene-O-ring
Ethylene Propylene O-ring
Vessel Support - Optional
5/ 16 UNC, 18-8 Stainless Steel
Not shown in above cross section
