Pentair HIGH POWER WIRELESS LINK KIT - Indoor Transceiver LEDs and Connectors

High Power Wireless Link Kit Installation Guide
4
5
PWR: Green LED on: Power is on to the unit.
RX: Yellow LED indicates the unit is receiving data.
TX: Green LED indicates the unit is transmitting data.
ID number
(Outdoor transceiver)
IMPORTANT NOTICE: Be sure the
yellow ID label (8-digit ID number
XXXXXXXX) located on the front side
of the Indoor transceiver and the ID
number on the outdoor transceiver
circuit board are the same.
RS-485 Connector
(to Protocol Adapter,
ScreenLogic only)
High Power Wireless Link Indoor Transceiver LEDs and Connectors
High Power Wireless
Indoor Transceiver LEDs
RS-485 Connector
(to Protocol Adapter,
ScreenLogic only)
Ethernet Port
High Power
Wireless Indoor
Transceiver and
base
Power Plug
socket
2.16 in
1.75 in
Keep this side
clear of ALL
metal objects for
2 ft. (61 cm)
Model: HPW-WETHLINK
HVIN: HPW-WETHLINK
FCC ID: 2AHWAQTSHPWETH
ISED: 21176-QTSHPWETH
HIGH POWER
WIRELESS LINK
