INTELLICHLOR
®
Salt Chlorinator Installation Guide
3
Install the Power Center at eye level as close to the IntelliChlor Salt
Chlorinator pump and filtration as possible.
The IntelliChlor Salt Chlorinator power center must be installed more than 8 ft.
(2.44 m) from the pool edges. Leave sufficient clearance on all sides of the
Power Center. Ensure that the 15 ft. (4.61 m) DC power cord from the Cell
assembly pipe location can reach the Power Center location. The Power
Center enclosure can be mounted on the wall up to 15 feet away from the cell
controller.
Note: For installation instructions about connecting the cell to Power Center,
see the “IntelliChlor User’s Guide” (P/N 520589).
IMPORTANT SAFETY PRECAUTIONS. PLEASE READ THE
FOLLOWING: Read all the safety precautions in this manual
before attempting any electrical wiring. Be sure to read and follow all safety
Instructions on page ii. Wiring should only be performed by a qualified
professional. When using electrical products, basic precautions should always be
followed, including the following:
RISK OF ELECTRIC SHOCK, WHICH CAN RESULT IN
SERIOUS PERSONAL INJURY OR DEATH.
Before attempting installation of service, ensure that all power to the
circuit supplying power to the system is disconnected/switched off at
the circuit breaker. When using IntelliChlor Salt Chlorinator with an
IntelliTouch
®
Control System, it is recommended to wire the
IntelliChlor Salt Chlorinator Power Center to the pump side of the relay located in the
IntelliTouch Control System Load Center. This wiring method does not require a
ground fault circuit-interrupter (GFCI) to protect the circuit. A green colored terminal (or
a wire connector marked “G”, “GR”, “Ground” or “Grounding”) is provided within the
terminal compartment in the Power Center transformer enclosure. To reduce risk of
electric shock, connect this terminal or connector to the grounding terminal of your
electric service or supply panel with a conductor equivalent in size to the circuit
conductors supplying this equipment. The power supply must be interconnected with
pool pump motor power source. This insures the IntelliChlor Salt Chlorinator and pool
pump will switch on and off together.
• Grounding (earth bonding) is required. The unit should be installed by a
qualified service person and grounded.
• Install the IntelliChlor Salt Chlorinator enclosure a minimum of two (2)
feet from the heater outlet.
• Allow ample access to the IntelliChlor Salt Chlorinator control panel
buttons and the IntelliChlor Salt Chlorinator Power Center.
• Pipe couplings: Schedule 80, maximum pressure 150 psi at 70° F.
• Operate unit with minimum flow of 20 gpm. For high flow applications,
use a bypass loop.
Installing the IntelliChlor
®
Salt Chlorinator Power Center
