Pentair Tagelus TA 100D User Manual

8
Tagelus
®
Sand Filter Installation and User’s Guide
TAGELUS
®
SAND FILTER
LEDOM.MIDA.MIDB.MIDC
04AT.ni64.ni73.ni¾81
05AT.ni½05.ni½83.ni¼12
orPraelC06AT
®
.ni75.ni½24.ni½42
D04AT.ni74.ni73.ni½91
D05AT.ni½15.ni½93.ni½12
D06AT.ni75.ni½24.ni½42
D001AT.ni½56.ni¼74.ni½03
DETAIL B
Before Dec. 1, 1991
6" "V" THREAD
DETAIL A
After Dec. 1, 1991
6" BUTTRESS THREAD
Filters manufactured after Dec 1, 1991 utilize a
6 in. buttress thread in the filter tank top opening
and on the closure, see Detail A.
Filters manufactured before Dec 1, 1991 utilize
a 6 in. “V” type thread, see Detail B.
6 in. closures in Detail A. and B. are NOT
interchangeable.
Section 4
Replacement Parts
15
13
6
9
10
11
12
7
4
3A
16
14
8
2A
17
1A
1B
5
DIM. D
3B
2B
17
5
(See Note 1)
TAGELUS
(Threaded Style Valve)
TAGELUS DELUXE
(Clamp Style Valve)
Clearance to remove valve & internal piping
C
B
A
IMPORTANT NOTICE
The valve adaptor used on TA 40D, 50D, and 60D
filters manufactured after November 1, 1994 has a
new face seal design with a square sealing ring
that is white in color, P/N 154494.
The black o-ring, P/N 154493, used on our
TA 40D, 50D, and 60D filters manufactured before
November 1, 1994 will NOT interchange with the
new 154494 sealing ring.
When ordering a replacement seal, be sure to
specifiy which seal your filter has in the adaptor.
TA 40 / TA 40D
TA 50 / TA 50D
TA 60 ClearPro
®
/ TA 60D
TA 100D
