1. SPECIFICATIONS
The aim of this handbook, we would like to give you the most important information about the correct
use and maintenance of the inverter; the models of FCP, differents for the voltage output are:
FCP109: Single-phase Inverter for Single-phase motor-pump, max. 1100W (1.5 Hp) for a maximum
current of 9A.
FCP111: Single-phase Inverter for Single-phase motor-pump, max. 1500W (2 Hp) for a maximum
current of 11A.
FCP307: Single-phase Inverter for Three-phase motor-pump, max. 1500W (2 Hp) for a maximum
current of 7A.
This Inverter is designed specifically for motor-pumps operation, all types not depending from the flow
or the pressure, with a perfect feedback control of pressure (detected with a pressure transducer), a
substantial energy savings (up to 40% on respect to the standard on-off system) combined with
various security features for the pump that are not possible in common appliances using pressure or
flow switch.
The following instructions are about the standard model only.
If you require thecnical assistance regarding specific parts at Service Sales please do specify the
exact initials of the model, followed by the number of the model, on the upper-left part of the product.
2. WORKING CONDITIONS
Simbol
Value
Meas. Unit
Ambient working temperature
T
amb
0..+40
°c
Maximum relative humidity
50
%
(40°C)
Protection grade of the Inverter
IP65
Protection grade of the pressure transducer
IP67
Nominal single-phase pump power connected to FCP109
P
2n
1100
1.5
W
Hp
Nominal single-phase pump power connected to FCP111
P
2n
1500
2
W
Hp
Nominal three-phase pump power connected to FCP307
P
2n
1500
2
W
Hp
Nominal voltage supply Inverter
V
1n
220-230
V
Range voltage supply Inverter
V
1
207..244
V
Frequency supply Inverter
f
1
50-60
Hz
Voltage single-phase Output for FCP109 – FCP111
V
2
V
1
V
Voltage three-phase Output for FCP307
V
2
3xV
1
V
Fequency Inverter Output
f
2
0..55
Hz
Nominal input current to the Inverter FCP109 – FCP111
I
1n
10
A
Nominal input current to the Inverter FCP307
I
1n
12
A
Maximum output single-phase current for FCP109 (ED100%)
I
2
9
A
Maximum output single-phase current for FCP111 (ED100%)
I
2
11
A
Maximum output three-phase current for FCP307 (ED100%)
I
2
7
A
Maximum output Inverter current for one second maximum
I
2p
3 x I
2n
A
Maximum pressure gauge
0 – 10
Bar
Resolution of pressure gauge
0.5
Bar
Storage temperature
T
stock
-20..+60
°C
Table 1: Working conditions
 Vibrations and hits: they must be avoided by a correct assemblage;
 For different environment conditions, please contact our Sales Department.
This Inverter can not be installed in explosive environments.
