ARS*-B2-IA*
Product Description
2024-03
11
• Reach length of up to 550 m
• LC duplex connector
• Multi-mode fiber with 850 nm wavelength
• Complies with a Class 1 laser product in accordance with EN 60825-1.
SFP-3
• Complies with IEEE 802.3z Fast Ethernet standard 100BASE-LX
• Transfer rate 100 Mbit/s
• Reach length of up to 30 km
• LC duplex connector
• Single-mode fiber with 850 nm wavelength
• Complies with a Class 1 laser product in accordance with EN 60825-1
• Fiber optic diagnostic monitoring.
SFP-4
• Complies with IEEE 802.3z Gigabit Ethernet standard 1000BASE-LX
• Transfer rate 1 Gbit/s
• Reach length of up to 10 km
• LC duplex connector
• Single-mode fiber with 850 nm wavelength
• Complies with a Class 1 laser product in accordance with EN 60825-1
• Fiber optic diagnostic monitoring.
For further SFP transceiver versions contact your Pepperl+Fuchs sales representative.
Protective Cover for RJ45 Sockets
Figure 2.5
To protect unused RJ45 sockets against dust or unintentional harm, protective covers are pro-
vided.
3
13.8
4.8
14.7
11.9
11.2
