Box Thin Client for Industrial Applications

BIOS Settings

2019-12

Figure 4.4 Serial Port

Figure 4.5 Mode Select

Settings for Serial Port 1

Device settings Mode select

IO=3F8h; IRQ=4;

IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12

IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12

IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12

IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12

RS-232

RS-422

RS-485

RS-422 Termination Resistor

RS-485 Termination Resistor
