Box Thin Client for Industrial Applications
Product Description
2019-12
9
Mechanical specifications
International approvals
Relative humidity 90 % at 40 °C (non-condensing acc. to EN 60068-2-
78)
Shock resistance 40 g (11 ms) when operating
Vibration resistance 3 g
rms
5 ... 500 Hz
Housing material aluminum body and sheet metal , painted/powder-
coated
Degree of protection IP4x
Mass 1.6 kg
Dimensions 260 mm x 200 mm x 56 mm
Mounting Desktop or wall mounting , VESA mount and DIN-rail
mounting via optional adapter
Note passive cooling , no moving parts
Power supply not included.
UL approval UL Listed for Canada and USA, E223772 (NRAQ,
NRAQ7) in preparation
Approved for CE, 2014/30/EU (EMC), 2011/65/EU (RoHS)
